8.17 BACK-UP UNIT
If the Transmitting Unit cannot be used, it can be replaced with a Transmitting Unit called
"BACK-UP UNIT"; you need to ask for it from Autec.
It is identical to the Unit that can no longer be used; the only dierence is the presence of
the plate “BACK-UP UNIT” on the battery housing.
Set DIP switch 2 in the "BACK-UP UNIT" as shown in the Technical Data Sheet.
If no "Key ID 0-1" or "ID internal tx memory" is present in the Transmitting
Unit that can no longer be used, perform the PAIR procedure to pair the
“BACK-UP UNIT” with a Receiving Unit (the Technical Data Sheet shows
which PAIR procedure to use).
If a "Key ID 0-1" or an "ID internal tx memory" is present in the Transmitting
Unit that can no longer be used, move it to the "BACK-UP UNIT" and perform
the address saving procedure described below.
As required by standard IEC 60204-32, each Radio Remote Control is uniquely
identied through a serial number. Therefore, upon replacement of the Unit,
the serial number of the Transmitting Unit to be replaced must be marked
on the "BACK-UP UNIT", so that all Units belonging to the Radio Remote
Control will show the same serial number.
Autec cannot be held responsible if the serial number of the Transmitting
Unit to be replaced has not been marked on the "BACK-UP UNIT".
Address storage
With fully charged battery and power keyswitch in the "BACK-UP UNIT", perform this procedure:
1. press the "Enabling&Stop" pushbutton halfway (ON - rst step, see paragraph 8.6),
2. press the START pushbutton and hold it down until the green and red LEDs light up,
3. wait until the green LED blinks slowly,
4. within 3 seconds, activate in sequence the commands corresponding to PIN 1, PIN 2 and
PIN 3 that compose the PIN code given in the Technical Data Sheet.
If the PIN code is incorrect, the red LED illuminates and the Transmitting Unit switches o.
In this case, the storage procedure shall be repeated.
If the PIN code is correct, the green LED turns steady on and the Transmitting Unit switches
o: this indicates that the address has been stored in the "BACK-UP UNIT". It is now
possible to start the Radio Remote Control and control the Machine with the "BACK-UP
UNIT" Transmitting Unit.
AUTEC - Air series
General operating instructions 41
LIULK1ES0_eng-01
