7 Light signals
7.1 Light signals on LK NEO 10 and LK NEO 12 Transmitting Units (Model
LKN Type LA2EM)
A Red LED
B Green LED
C
LEDs for "Data
Feedback" function
The LK NEO 10 and LK NEO 12 Transmitting Units always have a green LED [B] and a red
LED [A] that provide information regarding the Radio Remote Control.
Symbol Meaning
This symbol identi󰘰es the red LED [A].
This symbol identi󰘰es the green LED [B].
The meaning of signals provided by the LEDs identi󰘰ed with “C” are explained in
the "Data Feedback" function part (see paragraph 8.16). The meaning of LEDs
related to the "Data Feedback" function are decided and established by the
Machine Manufacturer depending on the Machine's functions for which he wants
to receive information.
7.1.1 Red LED [A] and green LED [B]
The meaning of red LED [A] and green LED [B] signals is described in the following tables;
possible actions to carry out are given in chapter 11.
The meaning of the red and green LED signals cannot be modi󰘰ed.
20
LIULK1ES0_eng-01
Light signals
