Autel Robotics EVO 2 - Specifications

63
These areas are set within 1 km (0.5 mi) of the center of the specified locations
where takeoff and flight are prohibited.
• Warning Zone
Once the aircraft enters a region within 2 km (1 mi) of the center of the Warning
Zone site, the app will display a warning message.
6.2 Specifications
Aircraft Specifications
Max. Take-off Weight
1000 g (2 lb 3 oz)
Hover Precision
GPS + Ultrasonic + IMU:
Horizontal: ±1.5 m (5 ft); Vertical: ±0.2 m (8 in);
Vision+IMU: Horizontal: ±0.1 m (4 in); Vertical:
±0.1 m (4 in)
Max. Yaw Rate
200 dps
Max. Inclination Angle
35°
Max. Ascent/Descent Speed
Ascent: 5 m/s (11 mph)
Descent: 3 m/s (7 mph)
Max. Horizontal Speed
20 m/s (45 mph)
Diagonal Wheelbase
338 mm (13 in)
Propeller Size
229 mm (9 in)
RF Frequency
2400 - 2483.5 MHz
902 - 928 MHz
Flight Modes
GPS Mode, ATTI Mode
Operating Environment Temperature
0°C to 40°C (32°F to 104°F)
