6
Denitions of Flight LED Indicator Status
Normal Status
RGY - Alternate Flashing System self-test is activated
YG - Alternate Flashing The aircraft is warming up
G - Slow Flashing
The aircraft is in GPS mode
Warning
Y - Slow Flashing The aircraft is in ATTI mode
Y - Fast Flashing No connection between the aircraft and remote control
R - Slow Flashing Low Battery Warning
R - Fast Flashing Critically Low Battery Warning
R - Solid Light Critical problems, IMU error
RY - Alternate Flashing
Abnormal compass, calibration is required /
Magnetometer interference
Compass Calibration
Y - Fast Flashing
Be ready to calibrate the compass / The aircraft is
calibrating
G - Solid Light Calibration is successful
R - Solid Light Calibration is failed
2.1.3 Aircraft Battery
EVO’s custom-designed, rechargeable Li-Po battery with a capacity of 4300mAh
can provide up to 30 minutes of continuous ight with a full charge. It should be
charged exclusively using the supplied charger.
Basic Functions
