4.2 Details
The Details screen shows a wide variety of tire wear information. After
measurements are shown on the screen, select a wheel location, swipe left
to view details of the chosen tire. Below are the main sections featured in
the Details section:
1) Graphic measurements — shows the measurement data graphically
with various colors indicating different degrees of tire wear.
The graphic measurements of the All Tread check mode displays
the wear measurements of three areas of the tire: inner, center,
and outer. The Single check displays only one measurement for
each tire.
2) Braking distance — displays the stopping distance for the test vehicle
based on both the tire tread depth and tire type selected. This section
is followed by wear analysis and maintenance suggestions.
The following three tire-related sections are provided in all check modes
except for Brake Disc:
3) Tire condition — displays tire status, including normal, worn, bulge,
etc.
4) Tire DOT — scan or manually enter the tire DOT serial number located
on the sidewall to acquire basic tire characteristics such as tire recall
(American region only) and tire age.
5) Tire specification — view a series of options and manually enter tire
information, including brand, tire model, size, structure type code, etc.
Figure 4-2 Details Screen
