2 General Introduction
The Autel MaxiTPMS TBE200 Examiner (hereinafter referred to as “the tool”)
is a laser-enabled tire & brake disc-wear examination tool that provides users
with quick and accurate tire-wear measurements along with the ability to
measure brake disc wear without having to remove tires. The tool's dual
cameras enable users to document tire wear and damage as well as scan
Tire Identification Numbers (TINs). You can use the tool on its own or with a
compatible Autel diagnostics tablet, such as an ITS600/ITS600 Pro to view
and print detailed TPMS reports.
This manual describes the construction and operation of the tool and how it
works to test tire & brake disc wear.
2.1 MaxiTPMS TBE200 Examiner
2.1.1 Functional Description
Figure 2-1 Examiner Top View
1. Type-C USB Rubber Plug
2. Type-C USB Port
