Auto Mate AM6.2 - Wiring Diagrams: Primary and Satellite Harnesses; Primary Harness (H1) Connections; 4-Pin Satellite Harness Connections

10 © 2007 Directed Electronics—all rights reserved
primary harness (H1) wiring diagram
______
______
______
______
______
______
______
______
______
4-pin satellite harness diagram
______
______
______
______
PINK (-) IGNITION TRIGGER
PURPLE (-) STARTER TRIGGER
ORANGE (-) ACCESSORY TRIGGER
BLUE (-) STATUS OUTPUT
1
2
3
4
WHITE (+/-) LIGHT FLASH
BLACK (-) GROUND
RED/WHITE NO FUNCTION
WHITE/RED (+) ACTIVATION INPUT
GRAY/BLACK (-) WAIT TO START INPUT
WHITE/BLUE (-) ACTIVATION INPUT
YELLOW (+) IGNITION OUT (TO ALARM)
GREEN/WHITE (-) FACTORY REARM
LIGHT GREEN/BLACK (-) FACTORY ALARM DISARM
H1/1
H1/2
H1/3
H1/4
H1/5
H1/6
H1/7
H1/8
H1/9
