Auto Mate AM6.2 - Additional Wiring Harness Diagrams; Heavy Gauge Relay Wiring; Door Lock Harness (3-Pin); Remote Start Harness (H2) Connections

© 2007 Directed Electronics—all rights reserved 11
heavy gauge relay wiring diagram
______
______
______
______
______
______
door lock harness, 3-pin connector
______
______
______
Note: Refer to TechTip 1041 for wiring information.
remote start harness (H2) wiring diagram
______
______
______
______
______
BLUE/WHITE (-) 200 mA 2ND STATUS/REAR DEFOGGER OUTPUT
GRAY (-) HOOD PINSWITCH SHUTDOWN WIRE
BROWN (+) BRAKE SWITCH SHUTDOWN WIRE
VIOLET/WHITE TACHOMETER INPUT WIRE
BLACK/WHITE (-) NEUTRAL SAFETY SWITCH INPUT
H2/1
H2/2
H2/3
H2/4
H2/5
BLUE (-) UNLOCK OUTPUT
EMPTY NOT USED
GREEN (-) LOCK OUTPUT
1
2
3
RED (+) (30A) HIGH CURRENT 12V INPUT
PINK/WHITE (+) PROGRAMMABLE OUTPUT FOR ACCESSORY OR IGNITION
RED (+) (30A) HIGH CURRENT 12V INPUT
ORANGE (+) (30 AMP) OUTPUT TO ACCESSORY CIRCUIT
PURPLE (+) (30 AMP) OUTPUT TO STARTER CIRCUIT
PINK (+) (30 AMP) OUTPUT TO IGNITION CIRCUIT
1
2
3
4
5
6
