what is included
■ The control module (see diagram)
■ Two remote transmitters
■ The plug-in program switch
■ A hood pinswitch
■ A toggle override switch
■ HX antenna receiver
6-pin relay output
4-pin satellite/
harness
9-pin main harness
5-pin remote start
harness
4-pin/3-wire
receiver port
3-pin/2-wire door
lock harness
2-pin BLUE
program plug
status LED
