30 © 2007 Directed Electronics—all rights reserved
features menu
The factory default settings are indicated in bold text in the table below.
FEATURE LED ON SETTING LED OFF SETTING
NUMBER
1 Engine checking on Engine checking off
2 Tachometer checking type Voltage checking type
3 12 minutes run time (1)* 24 minutes (2)*, 60 minutes (3) run time
4 Flashing parking light output Constant parking light output
5 Cranking time 0.6 sec. (1) Cranking time 0.8 (2), 1.0 (3), 1.2 (4), 1.4 (5),
1.6 (6), 1.8 (7), 2.0 (8), 4.0 (9) sec.
6 Voltage check high level Voltage check low level
7 No function
8 Activation pulse: 1 (1) Activation pulses: 2 (2), 3 (3)
9 Ignition/accessory output: Ignition Ignition/accessory output: Accessory
10 Accessory state during wait to start: OFF Accessory state during wait to start: ON
11 2
nd
status output: Normal (1) Rear defogger latched (2)/pulsed (3)
12 Diesel timer Wait-to-Start input (1) Timed 15 (2), 30 (3), 45 (4) seconds
13 No function
14 Door Lock pulse duration 0.8 seconds (1) 3.5 (2), 0.4 (3) seconds
15 Unlock output 1 pulse Unlock output 2 pulses
16 Lock output 1 pulse Lock output 2 pulses
17 Ignition unlock ON Ignition unlock OFF
18 Ignition lock ON Ignition lock OFF
19 Factory Alarm Disarm function with unlock Before Unlock (2)/Remote Start only (3)
20 Factory Alarm Disarm 1 pulse 2 pulses
21 No Function
*NOTE: The number in parentheses indicate the number of times the LED will flash
