1212
--SETUP MENU--
CONFIGURE TESTER
SET DATE & TIME
>CLEAR LAST TEST
CLEAR ALL TESTS
SET LANGUAGE
--SETUP MENU--
CONFIGURE TESTER
SET DATE & TIME
CLEAR LAST TEST
>CLEAR ALL TESTS
SET LANGUAGE
--SETUP MENU--
CONFIGURE TESTER
SET DATE & TIME
CLEAR LAST TEST
CLEAR ALL TESTS
>SET LANGUAGE
--LANGUAGE--
>SELECT LANGUAGE:
ENGLISH.
USE +/-.
'Y' TO SELECT.
CLEARING TESTS AND SETTING LANGUAGE
Select CLEAR LAST TEST from
memory. You will be asked to verify
your selection after which the BVA-
2100 will clear the last test.
Select CLEAR LAST TEST from
memory. You will be asked to verify
your selection after which the BVA-
2100 will clear the last test.
You can set for English or Spanish
3737
The vehicles data will appear.
Much of the information accessed,
such as the oil temperature will be
use in the calculating test results.
Press (Y Enter).
You will be instructed to connect
the large leads. Connect the red
clamp to the main positive cable
coming to the bank and the black
clamp to the main negative cable
leaving the bank.
Using the (+) or (-) key adjust the
CCA of an individual battery. If each
battery varies in CCA approximate
an average. If the CCA is unknown
consider that most truck batteries
range from 625-950 CCA.
Press (Y Enter) to begin the test
and wait for results. Example is
at the top of page 10 (Individual
Batter Test).
Using the (+) or (-) key adjust the
temperature in units of 10 degrees.
This should be the temperature of
the battery(S). Consider where the
vehicle has been before adjusting.
BATTERY BANK (Cont.)
Black
Clamp at
Negative
Main
Red Clamp
at Positive
Main
Battery Bank
of 3 Batteries
--BATTERY BANK--
>VIN: 123456789A
BATTERY 12.65V.
OIL TEMP 68F
'Y' TO CONTINUE
--BATTERY BANK--
>CONNECT LARGE
LEADS TO THE
BATTERY BANK
'Y' TO CONTINUE
--BATTERY BANK--
>ENTER SINGLE
CCA 650
12.39V
'Y' TO BEGIN
--BATTERY BANK--
>ENTER BATTERY
TEMP. 70F.
12.39V
'Y' TO CONTINUE
--BATTERY BANK--
>TESTING BANK
PLEASE WAIT...
To Next Page
