Auto Meter BVA-2100 - Table of Contents

46
NOTES TABLE OF CONTENTS
Specications ................................................................. 2
Safety ............................................................................. 4
Cause of Battery Failure ................................................. 4
Inspection and Visual Check .......................................... 5
Controls and Functions................................................... 6
Conguring the BVA-2100 ........................................... 7-9
Test Sections
1. PM Test ................................................................. 10
2. Battery Bank Test ............................................. 11-12
3. Individual Battery Test ...................................... 13-14
4. Charging System Test ...................................... 15-19
5. Charging Cable VDrop Test .............................16-17
VDrop Error messages ......................................... 17
6. Individual Alternator Test ....................................... 18
Alternator Test Results .......................................... 19
Using the Amp Probe ............................................ 20
7. Starting System Test ........................................ 21-28
8. Magnetic Circuit Test ........................................ 22-24
9. Starting Cable VDrop Test ............................... 25-26
10. Individual Starter DrawTest ................................... 27
Starter Test Results ............................................... 28
11. Liftgate & Generic VDrop Tests ........................ 29-30
Other Menu Options
Review Tests ........................................................ 31
(Optional) Printer .............................................. 31-32
Printing Test Results ............................................. 32
Multimeters ................................................................... 33
J1708 Data .............................................................. 34-35
Setup ....................................................................... 36-37
Clearing Test and Setting Language ............................ 37
PC Download Innterface............................................... 38
Using Windows ...................................................... 39
Downloading Test Information ............................... 40
Capturing Text in Microsoft Excel .......................... 40
About ............................................................................ 41
Battery and VDrop Test System Specications ............ 42
