Current ClampVoltmeter
This screen will appear and
display the measured DC and
AC currents.
To use the Voltmeter function,
press the Voltmeter button on
the Main Menu.
To use the Current Probe to
measure current going
through a cable, Press the
Current Probe button.
This screen will appear
and show the DC
voltages on the large
and small clamps. If
the engine is running
the ripple (AC Voltage)
will be measured and
displayed.
USING THE CURRENT PROBE
The Current Probe is optional. This section explains the proper use of the Current Probe, but is not required to
run any of the tests. It only provides assured accuracy for those wanting these results.
When the probes is not connected push
and turn to Zero the current probe.
Arrow located
on edge of Probe
Direction of Current
To Next Page
