Automated Logic OptiFlex FIO User Manual

OptiFlex™ I/O Expanders (part no. FIO)
Automated Logic Proprietary and Confidential A Carrier Company. © 2022 Carrier.
Rev. 7/12/2022
All rights reserved.
25
5 Anything other than No Fault Detected indicates an error. See the table below to determine the
error and possible actions to take.
Reliability
description
Possible error
Verify that...
Communication
Failure
•
Expander is not connected to the
controller.
• The expander has no power.
•
The controller is offline.
•
The expander is connected to the
controller's I/O bus edge connector or
wired to the I/O Bus port.
•
The expander has power.
Configuration
Error
• The microblock's I/O Type and
Sensor/Actuator Type
are not
compatible.
• The I/O Type and Sensor/Actuator
Type
combination is valid for the I/O
number and microblock type.
•
The output's DIP switch setting
does not match the connected
device.
•
The DIP switch setting is appropriate
for the output and microblock type.
•
Invalid expander address or I/O
number.
•
The expander is present and
functional at the address shown in
the WebCTRL® interface and that I/O
number is valid.
Over Range
•
Input exceeds the
Min/Max
limits.
•
The input is within the
Min/Max
limits.
No Output
•
Output's
Hand-Auto-Off
switch is in
Hand or Off position.
•
The expander's
Hand-Auto-Off
switch is in the Auto position.
No Sensor
• No device is attached to the output.
• The device is present and functioning.
Shorted Loop
•
Internal voltage feedback does not
correspond with commanded value.
•
The load on the output is within the
valid range.
• A voltage/current source has not
been connected to an output.
Open Loop
•
Internal current feedback does not
correspond with commanded value.
•
The load on the output is within the
valid range.
• A voltage/current source has not
been connected to an output.
Unreliable Other
• Feedback from the expander does
not correspond with commanded
value (for example, the output relay
is not in commanded state).
• Expander may be faulty. Contact
Technical Support.
