OptiFlex™ I/O Expanders (part no. FIO)
Automated Logic Proprietary and Confidential A Carrier Company. © 2022 Carrier.
All rights reserved.
4
Specifications
Power 24 Vac ±10%, 50–60 Hz, 50 VA
26 Vdc ±10%, 12 W
I/O Bus port Provides communication for wired FIO expanders that are powered by
external power supplies. The port's
switch can be used to
terminate the expander network.
I/O bus edge connector 6-pin connector that provides communication and power to a
directly-connected FIO expander. See FIO expander configurations to
determine how many FIO expanders you can use with the edge connector.
Inputs
FIO012u
FIO48u
FIO812u
FIO88u
12 inputs
8 inputs
12 inputs
8 inputs
Inputs are configurable in the control program for 0–5 Vdc, 0–10 Vdc,
0–20 mA, RTD, thermistor, dry contact, or pulse counter.
Input resolution 16 bit A/D
