Module Clock
Clock Fail Date and Time
Date and time control program uses when module's real-
time clock is invalid.
TIP Use an occupied date and time (such as a Tuesday
at 10 a.m.) so the equipment does not operate in
unoccupied mode if the module loses power during
occupancy.
Time Synch Sensitivity
(seconds)
On a Time Synch signal, update the module clock only if
the module time differs from the signal time by more
than this value.
Device
On this page, you can change the following properties:
• BACnet device object properties for the ZN551
• ZN551 network communication
Configuration
NOTE The three APDU fields refer to all networks over
which the ZN551 communicates.
Max Masters and Max Info
Frames
Apply only if the ZN551's parent network is an MS/TP
network.
Notification Class #1
WebCTRL alarms use Notification Class #1. A BACnet alarm's Notification
Class defines:
• Alarm priority for Alarm, Fault, and Return to Normal states
• Options for BACnet alarm acknowledgement
• Where alarms should be sent (recipients)
NOTE You may need to set up additional Notification Classes if your system
will handle Life Safety alarms or if you need to send certain types of alarms
only to an alarm manager other than WebCTRL.
Priorities
NOTE BACnet defines the following Network message
priorities for Alarms and Events.
Priority range Network message priority
00–63 Life Safety
64–127 Critical Equipment
128–191 Urgent
192–255 Normal
Priority of Off-Normal BACnet priority for Alarms.
Priority of Fault BACnet priority for Fault messages.
Priority of Normal BACnet priority for Return-to-normal messages.
ZN551 Control Module • Rev. 3/17/2005 14 © 2005 Automated Logic Corporation
