4 Set the communication type and baud rate.
For...
Set Communications
Selection jumper to... Set DIP switches 1 and 2 to...
ARC156 ARC156 N/A. Baud rate will be 156 kbps
regardless of the DIP switch settings.
MS/TP MSTP The appropriate baud rate. See the MSTP
Baud diagram on the control module.
NOTE Use the same baud rate for all control modules on the network
segment.
5 Insert the power screw terminal connector into the ZN551's power
terminals.
6 Verify communication with the network by viewing a module status
report in WebCTRL.
Wiring inputs and outputs
Wire the ZN551's inputs and outputs as follows.
Wiring specifications
Input wiring
Input Maximum length Minimum gauge Shielding
0–5 Vdc
1000 feet
(305 meters)
26 AWG Shielded
Thermistor
Dry contact
1000 feet
(305 meters)
22 AWG Shielded
RS room sensors
500 feet
(152 meters)
22 AWG,
4 conductor
1
Shielded or
unshielded
LogiStat
100 feet
(30 meters)
22 AWG
2
Unshielded
1
See the RS Room Sensors Technical Instructions (http://info.automatedlogic.com).
2
See the LogiStat Sensors Technical Instructions (http://info.automatedlogic.com).
Output wiring
To size output wiring, consider the following:
• Total loop distance from the power supply to the control module, and
then to the controlled device
NOTE Include the total distance of actual wire. For 2-conductor wires,
this is twice the cable length.
• Acceptable voltage drop in the wire from the control module to the
controlled device
• Resistance (Ohms) of the chosen wire gauge
• Maximum current (Amps) the controlled device requires to operate
ZN551 Control Module • Rev. 3/17/2005 6 © 2005 Automated Logic Corporation

Automated Logic ZN551 Specifications

General

Brand	Automated Logic
Model	ZN551
Category	Network Router
Language	English
