Automation Direct CTT-1C-A120 User Manual

Digital Counter / Timer / Tach User Manual, 1st Ed.
1-800-633-0405
2-4
Quadrature (
Ud C
)*
When the quadrature input signal at CP1 changes before the input signal at CP2, the trailing edge of CP2 will incre-
ment the count present value PV by 1.
When the quadrature input signal at CP2 changes before the input signal at CP1, the leading edge of CP2 will decre-
ment the count present value PV by 1.
Addition (
Add
)**
Each leading edge of the input signal at CP1 will increment the count present value PV by 1.
Each leading edge of the input signal at CP2 will increment the count present value PV by 1.
Subtraction (
SUb
)**
Each leading edge of the input signal at CP1 will increment the count present value PV by 1.
Each leading edge of the input signal at CP2 will decrement the count present value PV by 1.
*Available only with counter functions 1-stage, 2-stage, batch, total
**Available only with counter function dual
Step 3: Determine the Counter Output Mode by Visiting the Page Numbers Shown for Your Desired
Counter Function and Input Mode
Counter Output Modes:
Counter
Function
Counter Input Mode Page Number
1-Stage
Counting Up (
UP
)
2-5
Counting Down (
DOWN
)
2-9
Counting UP/Command Counting Down (
UdA
)
2-13
Counting UP/Counting Down (
UdB
)
2-18
Counting Quadrature (
UdC
)
2-23
2-Stage
Counting Up (
UP
)
2-28
Counting Down (
DOWN
)
2-33
Counting UP/Command Counting Down (
UdA
)
2-38
Counting UP/Counting Down (
UdB
)
2-45
Counting Quadrature (
UdC
)
2-52
Batch
Counting Up (
UP
)
2-59
Counting Down (
DOWN
)
2-64
Counting UP/Command Counting Down (
UdA
)
2-69
Counting UP/Counting Down (
UdB
)
2-75
Counting Quadrature (
UdC
)
2-81
Total
Counting Up (
UP
)
2-87
Counting Down (
DOWN
)
2-92
Counting UP/Command Counting Down (
UdA
)
2-97
Counting UP/Counting Down (
UdB
)
2-103
Counting Quadrature (
UdC
)
2-109
Dual
Addition (
Add
)
2-115
Subtraction (
SUB
)
2-120
Click on the above thumbnail or go to
https://www.automationdirect.com/VID-RL-0004
for a short Counter demo video.
Click on the above thumbnail or go to
https://www.automationdirect.com/VID-RL-0003
for a Counter Set-up video.
