SE3-USER-M
4
1st Edition, Dec. 2023
SE3 Series Industrial Unmanaged Ethernet Switches User Manual
Product Overview
e SE3 series industrial unmanaged switches are rated IP30, with one model rated IP67, and can be DIN
rail mounted or wall mounted. e series oers:
• 10/100Tx Fast Ethernet ports
• Up to twelve 10/100/1000Tx Gigabit Ethernet ports
• Power-over-Ethernet options in Fast Ethernet and Gigabit Ethernet (IEEE 802.3at compliant, 30W/port)
• 100Mbps SC and ST ber ports with multi-mode support
• Up to four 100/1000Mbps SFP slots, suitable for high bandwidth and long-distance communication
• An IP67 rated model with 10/100Tx Fast Ethernet M12 ports
• Auto-detection of MDI or MDI-X on all copper ports (RJ45 or M12)
• High EFT and ESD protection
• Power redundancy with a dual power input design with reverse polarity protection
• Built-in relay warning function on most models to alert users of power failures
• Standard operating temperature of -10 ~ 65°C, and extended operating temperature of -40 ~ 75°C,
to meet the needs of industrial automation applications and harsh environments.
SE3 Unmanaged Switches
Stride SE3 Unmanaged Models
Part Number
RJ45
10/100
RJ45
GbE
M12
10/100
Fiber
Input Power
(Max.)
IP
Rating
Operating Temperature
SE3-SW5U
5 – – 1.2 W
IP30
-10 to +65°C [14 to 149°F]
SE3-SW8U
8 – – 2.2 W
SE3-SW5U-T
5 – – 1.2 W
-40 to +75°C [-40 to 167°F]
SE3-SW8U-T
8 – – 2.2 W
SE3-SW5UG-T
– 5 – 6.6 W
SE3-SW8UG-T
– 8 – 9.2 W
SE3-SW5U-1C1-T
4 – 1 SC 5W
SE3-SW5U-1T1-T
4 – 1 ST 5W
SE3-SW6U-2C1-T
4 – 2 SC 6W
SE3-SW6U-2T1-T
4 – 2 ST 6W
SE3-SW7U-2P-T
5 – 2 SFP* 8W
SE3-SW5UG-1P-T
– 4 1 SFP* 5.6 W
SE3-SW10UG-2P-T
– 8 2 SFP* 12W
SE3-SW16UG-4P-T
– 12 4 SFP* 15.4 W
SE3-SW5U-N67-T
– – 5 – 0.5 W IP67
* Optional SFP modules sold separately.
