나 2 Specifications
© Copyright Reserved Autonics Co., Ltd. 17
2 Specifications
Series
CTS
CTY
CTM
Model
1-stage preset
CT4S-1P□□ CT6S-1P□□ CT6Y-1P□□ CT6M-1P□□
2-stage preset
CT4S-2P□□ CT6S-2P□□ CT6Y-2P□□ CT6M-2P□□
indicator -
CT6S-I□□ CT6Y-I□□ CT6M-I□□
Display digit 4-digit 6-digit 6-digit 6-digit
Display method 7-segment (counting value: red, setting value: green) LED method
Character
size
(W × H)
Counting value
6.5 × 10mm
4.5 × 10mm
4.2 × 9.5mm
6.6 × 13mm
Setting value 4.5 × 8mm 3.5 × 7mm 3.5 × 7mm 5 × 9mm
Power
supply
AC voltage 100-240VAC 50/60Hz
AC/DC voltage 24VAC 50/60Hz, 24-48VDC
Permissible voltage range 90 to 110% of rated voltage
Power
consumption
AC voltage Max. 12VA
AC/DC voltage AC: Max. 10VA, DC: Max. 8W
Counter
INA/INB max.
counting speed
Selectable 1cps/30cps/1kcps/5kcps/10kcps
Counting range -999 to 9999 -99999 to 999999
Scale
Decimal point
up to third digit
Decimal point up to fifth digit
Min. signal width RESET signal: Selectable 1ms/20ms
Timer
Time
range
4-digit 9.999s, 99.99s, 999.9s, 9999s, 99m59s, 999.9m, 9999m, 99h59m, 9999h
6-digit
999.999s, 9999.99s, 99999.9s, 999999s, 99m59.99s, 999m59.9s, 9999m59s,
99999.9m, 999999m, 99h59m59s, 9999h59m, 99999.9h
Operation method Count up, Count down, Count up/down
Min. signal width INA, INH, RESET signal: Selectable 1ms/20ms
INA, INHIBIT,
RESET, BATCH
RESET signal:
Selectable 1ms /
20ms
Repeat error
In case of power ON start: Max. ±0.01% ±0.05s
In case of signal ON start: Max. ±0.01% ±0.03s
SET error
Voltage error
Temperature error
Input method
Selectable voltage input or no-voltage input
[Voltage input]-input impedance: 5.4kΩ, [H]: 5-30VDC, [L]: 0-2VDC
[No-voltage input]-short-circuit impedance: Max. 1kΩ, short-circuit residual
voltage: Max. 2VDC
One-shot output time 0.01s to 99.99s setting
