• Input and output are insulated from the
power.
ADC input
circuit and
display part
Power
1 32 4 5 6
10
Dimensions
• Unit: mm, For the detailed drawings, follow the Autonics website.
91.5
48
44.4
4 20
Bracket
22
4.9
92
+0.8
0
45
0
Terminal cover
15.5
15.9
This is only for reference, the actual product does not support all combinations.
MX 4 W - - F
V: DC / AC voltage
A: DC / AC current
N: Indicator
1: NPN open collector
2: PNP open collector
Connections
• For using DC power, connect wires regardless of polarity.
HOLD / ZERO
SOURCE
COM
1 2 3 4 5 6 10
MX4W-V- MX4W-A-
DC
± 20 mA / 4 - 20 mA / ± 5 mA / ± 2 mA
AC
0 - 20 mA / 0 - 5 mA / 0 - 2 mA
DC
± 500 mA / ± 200 mA / ± 50 mA
AC 0 - 500 mA / 0 - 200 mA / 0 - 50 mA
DC
± 5 A / ± 2 A
AC
0 - 5 A / 0 - 2 A
•
COMOUT2OUT1
1 2 3 4
HOLD/
ZERO
•
COMOUT2OUT1
1 2 3 4
HOLD/
ZERO
Model MX4W-V- MX4W-A-
DC / AC voltage DC / AC current
allowable
+DC input
-DC input
AC input
12-segment LCD
01)
- : white, character height: 19 mm
- : red, green, yellow (indicator: white)
± 0.1 % F.S. rdg ± 2-digit ± 0.1 % F.S. rdg ± 2-digit
02)
0.2 to 5.0 sec (select per 0.1 sec)
-9999 to 9999 (4-digit)
conversion method
50 ms
Resolution 1 / 20,000
P NPN / PNP open collector output model
Load voltage
Load current
Residual voltage
output operates normally.
terminal
terminal
Insulation resistance
B
± 2 kV square wave noise (pulse width: 1
Vibration
Vibration
Shock
2
100 m/s
2
Ambient humidity
, (dielectric strength
between the measurement input part and the power part:1 kV)
