2.4 Read holding registers (Func 03) / Preset single
register (Func 06) / Preset multiple registers (Func 16)
2.4.1 Parameter 1 group
No(Address) Func R/W Parameter
Description Setting Range Unit
Factory
Default
Note
400001 (0000)
03/06/16
R/W
S-T
SOFT START time
0 to 100 :
0
to
100
sec
3
400002 (0001)
03/06/16
R/W
U-T
SOFT UP time
0 to 100 :
0
to
100
sec
3
400003 (0002)
03/06/16
R/W
D-T
SOFT DOWN time
0 to 100 :
0
to
100
sec
3
400004 (0003)
03/06/16
R/W
L-L
Output low-limit value
0 to 100 :
0
to
100
%
0
400005 (0004) 03/06/16 R/W
H-L
Output high-limit value 0 to 100 : 0 to 100 %
100
400006 (0005) 03/06/16 R/W
SLP
Output slope 0 to 100 : 0 to 100 %
100
400007 to 400050
03/06/16
R/W
Reserved
2.4.2 Parameter 2 group
No(Address) Func R/W Parameter
Description Setting Range Unit
Factory
Default
Note
400051 (0032)
03/06/16 R/W
INT
Control input
420 /1-5 / 512 / ONF/
COM
-
420
400052 (0033)
03/06/16 R/W
C-M
Control method
PA
/
V-F
/
C-F
/
W-F
/
F-C / V-C / ONF
-
PA
SPR1
(single-phase)
PA / V-F / C-F / W-F/
F-C
/
ONF
-
PA
SPR3
(3-phase)
400053 (0034)
03/06/16 R/W
MAN
Output limit adjuster
(inside/outside)
I_R / E-R / E-I -
I-R
400054 (0035)
03/06/16
R/W
INB
Input correction
-99 to 99 :
-99
to
99
%
0.0
400055 (0036)
03/06/16
R/W
SPN
Input slope correction
-99 to 99 :
-99
to
99
%
0.0
400056 (0037)
03/06/16 R/W
DIS
Front display
IN / L-V / L-A / L-W -
IN
SPR1
(single-phase)
IN
/
U-V
/
V-W
/
W-U
/
U-A / V-A / W-A / L-W
-
IN
SPR3
(3-phase)
400057 (0038)
03/06/16
R/W
OCV
Overcurrent alarm value
0 to 120:
0
to
120
%
120
400058 (0039)
03/06/16 R/W
OCT
Overcurrent alarm delay
time
0 to 100: 0 to 100 sec
5
400059 (003A)
03/06/16 R/W
OVV
Overvoltage alarm value 0 to 120: 0 to 120 %
120
400060 (003B)
03/06/16 R/W
OVT
Overvoltage alarm delay
time
0 to 100: 0 to 100 sec
5
400061 (003C)
03/06/16 R/W
F-L
Full load auto
recognition
OFF / ON -
OFF
400062 (003D)
03/06/16 R/W
HBV
Heater break alarm
value
OF F, 10 to 100
:
OFF
,
10
to
100
%
10
400063 (003E)
03/06/16
R/W
ADR
Communication address
1 to 99 :
01
to
99
-
01
400064 (003F)
03/06/16 R/W
BPS
Communication speed
24 / 48 / 96 / 192 /
384
-
96
400065 (0040)
03/06/16
R/W
PRT
Communication parity bit
NON
/
EVE
/
ODD
-
NON
400066 (0041)
03/06/16 R/W
STP
Communication stop bit 1 / 2 -
2
400067 (0042)
03/06/16 R/W
RW.T
Communication
response waiting time
5 to 99: 5 to 99 ms
20
400068 (0043)
03/06/16
R/W
CMW
Communication write
EN.A
/
DS.A
-
EN.A
400069 (0044)
03/06/16 R/W
LOC
Lock OFF / LC1 / LC2 -
OFF
400070 (0045)
03/06/16
R/W
INI
Parameter reset
NO
/
YES
-
NO
400071 to 400100 03/06/16 R/W Reserved
