Autonics TM Series - Control Operation Group(Func: 03;06;16, RW: R;W)

2 Modbus Mapping Table
© Copyright Reserved Autonics Co., Ltd. 25
2.5.2 Control operation group(Func : 03/06/16, RW : R/W)
No(Address)
Parameter
Description
Setting range
Unit
Factory
default
TM2
TM4
4
00101(0064)
40
0051(0032)
CH1 RUN
/STOP
Control
output
r
un/stop
0: RUN 1: STOP
-
0
4
00102(0065)
40
0052(0033)
CH1 Multi SV No
Multi SV
No. selection
0: SV
-0 1: SV-1
2: SV
-2 3: SV-3
-
0
4
00103(0066)
4
00053(0034)
CH1 SV
-0
SV
-0 setting value
SV
low limit to
SV
high limit
℃
/℉
0
4
00104(0067)
4
00054(0035)
CH1 SV
-1
SV
-1 setting value
SV
low limit to
SV
high limit
℃
/℉
0
40
0105(0068)
40
0055(0036)
CH1 SV
-2
SV
-2 setting value
SV
low limit to
SV
high limit
℃
/℉
0
40
0106(0069)
40
0056(0037)
CH1 SV
-3
SV
-3 setting value
SV
low limit to
SV
high limit
℃
/℉
0
40
0107(006A)
to
40
0200(00C7)
40
0057(0038)
to
40
0100(0063)
CH1
reserved
4
01101(044C)
to
4
01200(04AF)
4
01051(041A)
to
4
01100(044B)
CH2
parameter – the same as above CH1
-
4
02051(0802)
to
4
02100(0833)
CH3
parameter - the same as above CH1
-
4
03051(0BEA)
to
4
03100(0C1B)
CH4
parameter - the same as above CH1
