Power Supply
Max. Power
Output Pressure
Filling Hose Length
Package Size
Max. Flow Rate
Container Empty Protection
AC 110/220V ±10%
35W
0.7-2.5bar
3.5m
285*230*370mm
1.6L/min
Yes
Product Size 180*215*280mm
2
Brake fluid is taken from its container by a pump operating at up
to 3.0 bar pressure and is continuously pumped into the brake
fluid reservoir. The individual wheel brake cylinders can then be
drained of their used brake fluid until the new brake fluid comes
through.
You thus avoid the regular emptying and filling operations, in
contrast to conventional systems and also avoid any resulting
water absorption in the brake fluid.
The pump used to fill the brake fluid reservoir is equipped with
pressure monitoring. Should it not be possible to build pressure or
should the pump pull in air, the pump switches itself off automati-
cally.
PRODUCT INTRODUCTION
Operating
principle
Technical
data
