3
PRODUCT STRUCTURE
Structure
diagram
The adapter (Different versions are available), used to connect
to the brake fluid reservoir, is not shown.
●
Filler hose ON / OFF switchA B
Start button Fuse
C D
Pressure balance hose Suction hose
E F
Power cord
Pressure regulator
G H
Pressure gauge
I
A
B
C
D
H
I
G
E F
