3.2 Specifications
1) Display: 2.4” TFT 262K true color
2) Operating Temperature: 0 to 60℃ (32 to 140 Fº)
3) Storage Temperature: -20 to 70℃ (-4 to 158 Fº)
4) External Power: 8.0 to 18.0 V power provided via vehicle battery
5) Dimensions: 124x77.4x23.5mm
6) Weight: 0.35kg
3.3 Accessories Included
1) User's Manual -- Instructions on tool operations.
2) USB cable - Used to upgrade the scan tool.
3.4 DTC Lookup
The DTC Lookup function is used to search for definitions of Code
stored in the built-in Code library.
1) From the Main Menu, use the UP/DOWN scroll button to select the
Code Lookup and press the ENTER button.
Query the fault code, press enter + up, the cursor to the left; press
enter + down, the cursor to the right.
For manufacturer specific codes , you'll need to select a vehicle make on an
additional screen to look for DTC definitions.
If definition could not be found (SAE or Manufacturer Specific), the scan tool
displays "DTC definition not found! Please refer to vehicle service"manual !"
6
DTC Lookup
Please input DTC:
The 1st range : P , C , B , U
The 2nd range : 0 , 1 , 2 , 3
The others from : 0 to F
Changing Data: [ ] or [ ]
Moving Cursor: ENTER+ [ ] or ENTER+ [ ]
Confirmation: ENTER
OBDII I/M Setup
Lookup Review About
EN
