SECTION 8 - INSTALLATION
8.1 Basic System Overview
The Pool Pilot
®
salt chlorination system is designed to operate in the following configurations:
Shown with automatic flow bypass manifold assembly 941-615AC:
Figure 17
Shown with the convection cell option (surge tank required).
