Page - 33
Cell X - Zero Volts/Zero Amps
Problem
There may be a problem with the cell or cell cord.
Typical Solution
1.
Check cell and cell cord connections. If cell is clean and all cords are seated properly and not
damaged, proceed to the next step.
2.
Turn off power to the unit by the power switch on the control panel and wait three (3) minutes. If the unit
was in Boost mode, deactivate the Boost cycle prior to powering off the unit.
3.
Power the unit on and put in Boost mode, or increase the purifier output to 100%, and let run for three
(3) minutes.
4.
Press the TEST button and record the displayed diagnostics information. Be sure to make note of the
cell amps and volts for each cell.
5.
Deactivate Boost mode or return purifier output to the original setting.
If high volts and low amps, check the cell and cell cord connections.
If test shows low volts and low amps, there may be a problem with the power module. Call your
local AutoPilot
®
service center or AquaCal AutoPilot Customer Support for assistance.
CELL X light is not green
Problem
Possible low cell amperage.
Typical Solution
Replace the cell.
Problem
The cell cord may be disconnected from the cell.
Typical Solution
Verify the cell cord is firmly seated onto the cell terminals.
Problem
A fuse may be blown on the power module.
Typical Solution
Replace the fuse. See "Accessing the Power Module" on page 10.
Problem
LED light on the control board is damaged.
Typical Solution
Replace the 830 control board.
