AUX FREEDOM Series User Manual

24
●Ground wire: Remove the grounding screw out of the electric bracket, cover the
grounding wire end onto the grounding screw and screw it into the grounding hole.
● Fix the cable reliably with fasteners (Pressing board).
● Put the E-parts cover back in its original place and fasten it with screws.
NOTE:
※ This manual usually includes the wiring mode for the different kind of A/C.
We cannot exclude the possibility that some special type of wiring diagrams
are not included.
※ The diagram are for reference only. If the entity is difference with this wiring
Diagram , please refer to the detailed wiring diagram adhered on the unit which
you purchased.
8-3 Installation of outdoor Unit
18 Packing list of the outdoor unit
NO.
Name
Quantity
Unit
1
Outdoor Unit
1
Set
2
Connecting pipe
2
PC
3
Plastic Strap
1
ROLL
4
Pipe Protection Ring
1
Set
5
Luting (putty)
1
PACKET
19 Selection of Installation location
Wiring Diagram

AUX FREEDOM Series Specifications

General

Power Supply	220-240V, 50Hz
Type	Split
Energy Efficiency Class Heating	A
Features	Auto Restart, Sleep Mode
Operating Temperature Range (Cooling)	18°C to 43°C
