Outdoor heat exchanger
(Condensation)
Capillary
(Throttling)
Super cooled liquid of high
pressure
Liquid of low
pressure
(also a little gas)
Gas of high pressure
& temperature
4-way valve
(Heat pump only)
15
5 Cooling Cycle
Indoor heat exchanger
(Evaporation)
Compressor
(Compression)
Steam-gas of low pressure
5-2 Cooling & Heating
4
Cooling Mode
Indoor Unit
Outdoor Unit
