1.5 Specifications
System
CPU
 Intel® LGA1155 Socket Supports 2nd /3rd Generation Core™ i7/ i5/ i3,
Pentium® and Celeron® Processors (Max. TDP at 95W)
BIOS
 AMI uEFI BIOS, 32Mbit SPI Flash ROM
System Chipset
 Intel® B75 Express Chipset
I/O Chip
 nuvoton NCT5532D
System Memory
 Two 240-pin DIMM Sockets Up to 16GB Dual Channel
Unbuffered ,non-ECC,DDR3 1066/ 1333 /1600MHz SDRAM
H/W Status
Monitor
 CPU & system temperature monitoring
 Voltages monitoring
Expansion
 1 x PCI-e x 16 Gen.3, 1 x PCI Express x 1, 1 x PCI
I/O
Rear Side External
I/O Connector
 1 x RJ-45 with dual deck USB2.0 connector
 1 x dual deck USB 3.0 connector
 1 x VGA
 1 x HDMI
 1 x DVI-D
 1 x Keyboard PS2 and 1 x Mouse PS2
 1 x Line-out and 1 x Mic in and 1 x Line-in
Internal I/O
Connector
 3 x SATA II connector , 1 x SATA III connector
 1 x 2 x 5 pin ,Pitch 2.54mm for RS-232 , Pin 9 without power
 1 x 2 x 5 pin, pitch 2.54mm connector for USB 2.0
 1 x 2 x 10 pin, pitch 2.0mm connector for USB 3.0
 1 x 1 x 4 pin, pitch 2.54mm CPU fan connector with smart fan function
supported
 1 x 1 x 3 pin, pitch 2.54mm System fan connector
 1 x horizontal type battery connector
 1 x 2 x 5 pin, pitch 2.54mm connector for front panel
 1 x 2 x 5 pin, pitch 2.54mm connector for front Audio
 1 x 2 x 5 pin, pitch 2.54mm connector for LPC
 1 x 1 x 3 pin, pitch 2.54mm connector for SPDIF
 1 x 1 x 12 pin, pitch 2.54mm connector for BIOS ME flash
 1 x 1 x 4 pin, pitch 2.54mm connector for Speaker Buzzer
 1 x 2 x 12 pin ATX power connector
 1 x 2 x 2 pin ATX 12V power connector
Display
