CONTENT OF PACKAGES
UNO SD, DUO SD & DUO GT
cardboard boxes with one speaker in each.
feet with Teflon glides (installed in the foot f rame mechanism of
the speaker on delivery).
spikes, as an alternative to the standard feet.
protective plates (with center recess) for the spikes, to protect
sensitive floors f rom damage.
Tool to adjust the lock nuts, equipment feet & spikes.
user manual
2 x
2 x
2 x
2 x
4 x
8 x
8 x
8 x
1 x
1 x
CONTENT OF PACKAGES
UNO SD, DUO SD & DUO GT
power cable (3m) for passive version
power cable (3m) for iTRON version
0,8m speaker cable between bass amplif ier & passive crossover. (Passive
version only)
0.8m XLR cable between bass amplifier & iTRON module.
(iTRON version only)
