UNPACKING
UNO SD & DUO SD
When unpacking and setting up the speaker, be aware of their
heavy weight! For this work we strongly recommend the assistance
of at least three or more persons!
Do not move or carry the speakers by holding the horn assembly.
The horns may get damaged.
Place the packaging carton upright, remove the clips and open the
carton.
Carefully pull the loudspeaker forward using recessed grips.
Carefully lay the loudspeaker on its back.
Remove the lower EPP packaging protection.
Carefully lift the speaker to the upright position and remove the
EPP packaging protection.
Use a wheel board (minimum size 70 x 70 cm) to transport the loud‐
speaker to its listening position. Note that the spherical horns can
be removed by unscrewing them counterclockwise. This makes it
easier to pass through narrow doorways.
UNPACKING
DUO GT
When unpacking and setting up the speaker, be aware of their
heavy weight! For this work we strongly recommend the assistance
of at least three or more persons!
Do not move or carry the speakers by holding the horn assembly.
The horns may get damaged.
Place the packaging carton upright, remove the clips and open the
carton.
Carefully pull the loudspeaker forward using recessed grips.
Carefully lay the loudspeaker on its back.
Remove the lower EPP packaging protection.
Carefully lift the speaker to the upright position and remove the
EPP packaging protection.
Use a wheel board (minimum size 70 x 70 cm) to transport the loud‐
speaker to its listening position. Note that the spherical horns can
be removed by unscrewing them counterclockwise. This makes it
easier to pass through narrow doorways.
1
2
3
4
5
INSTALLATION
INSTALLATION
1
2
3
4
5
