Pre-Installation Checklist
Issue 3 April 2006 19
Note:
Note: The 4630 IP Telephone does not support IEEE-standard power, and therefore
requires the Power Module.
The 4690 IP Conference Telephone is powered with a special LAN/power cable
with a power interface module included with this telephone.
Requirements to Verify for Each IP Telephone
10a. You have an extension number and an Avaya Communication Manager security
code (password) for each IP telephone.
Note: This checklist item applies only to H.323 telephones. However, to allow an
H.323 telephone user to sign on to a SIP telephone, you must also establish that
person’s User ID and Password on the SIP Enablement Services (SES) server.
10b. You have an OPTIM extension number and an Avaya Communication Manager
security code (password) for each SIP telephone. You have configured SIP
Enablement Services for each SIP telephone.
Note: This checklist item applies only to SIP telephones. However, to allow a SIP
telephone user to sign on to an H.323 telephone, you must also establish that
person’s User ID and Password on Avaya Communication Manager.
11. A Category 5e LAN jack is available at each telephone site.
12. Electrical power is provided to each telephone by a Telephone Power Module (DC
power jack) (must be ordered separately). If the LAN will supply IEEE-standard
power to the 4601/4602/4602SW/4606/4610SW/4612/4620/4620SW/4621SW/
4622SW/4624/4625SW/4630SW, no power module is required.
13. 1 Category 5e modular line cord is available for the connection between the IP
telephone and the PC.
14. Verify that the 4600 Series IP Telephone package includes the following
components:
● 1 telephone set
● 1 telephone handset, except the 4622SW and 4690 IP Conference
Telephones
● 1 H4DU 9-foot long (when extended) 4-conductor coiled handset cord,
plugged into the telephone and the handset, except the 4690 IP Conference
Telephone
● 1 Category 5 modular line cord for the connection from the IP telephone to the
Ethernet wall jack
● 4600 Series IP Telephone Safety Instructions (555-233-779)
● Power Brick for 4630 IP Telephones only
● Stylus for 4630/4630SW IP Telephones only
● Power Interface Module for the 4690 IP Conference Telephone only
15. IP telephones ship from the factory with H.323 software. Existing installations might
also have many IP telephones running H.323 software. For instructions on how to
convert between H.323 and SIP software, see Converting Software on Avaya 4600
Series IP Telephones on page 33.
Optional Items for Some IP Telephones
16. If applicable to your current installation, verify that the following equipment/
information is present:
● 30A Switched Hub (applicable to the 4612/4624/4630 only)
● Stand Instructions, packaged with certain IP telephones
