Computer-Telephony Integration (CTI) Enable/Disable
Issue 3 April 2006 53
Note:
Note: Press the Mute button momentarily. Do not press this button while pressing other
keys/buttons. The 4630/4630SW IP Telephones and the 4690 IP Conference
Telephone do not have a dedicated Hold button. For all other 4600 Series IP
Telephones, pressing the Hold button instead of the Mute button also works.
One of the following texts displays left-justified at the top of the display, depending on the
current value of the CTI:
2. Press the 1 or 0 button to enable or disable the CTI interface respectively, or the # button to
leave the current value. The following text displays left-justified at the top of the display:
where 497xx is the value of the UDP port for CTI.
3. Enter a valid value between 49714 and 49721, inclusive for the UDP Port for CTI.
The following text displays left-justified at the top of the display:
4. Press the * button to terminate the procedure, or the # button to save the new values.
If you press the # button, the following text displays.
The new values are saved, and the user interface is restored to its previous state.
If CTI=manual: CTI=manual
0=Off #=OK
If CTI=disabled: CTI=disabled
1=Manual #=OK
UDP Port=497xx
New=_
Save new value?
*=no #=yes
New value
being saved
