If a value different from the current PHY1STAT value is entered, the following text displays
left-justified at the top of the display:
4. Press the * button to terminate the procedure, or the # button to save the new value. If you
press the # button, the following text displays:
where status is the value of PHY2STAT, defined as:
● Status is disabled when PHY2STAT = 0
● Status is auto when PHY2STAT = 1
● Status is 10Mbps HDX when PHY2STAT = 2
● Status is 10Mbps FDX when PHY2STAT = 3
● Status is 100Mbps HDX when PHY2STAT = 4
● Status is 100Mbps FDX when PHY2STAT = 5
5. To change the PHY2 value, press *.
Depending on the current value, the next sequential valid PHY2 value is selected and
displayed as the status. For example, if the current value is 10Mbps HDX (2), pressing *
changes the value to 3 (10Mbps FDX). If the current value is 100Mbps FDX (5), pressing *
changes the value to 0 (disabled).
The following text displays left-justified at the top of the display:
6. Press the * button to terminate the procedure, or the # button to save the new values.
If you press the # button, the following text displays.
The new values are saved and a restart occurs automatically. The user interface is restored
to its previous state.
Save new value?
*=no #=yes
PHY2=status
*=change #=OK
Save new value?
*=no #=yes
New value
being saved
