AVAYA DEFINITY G3 / ProLogicx Confidential
The information contained in this document is provided by AVAYA Inc. to serve as a guide. See the disclaimer on page 1
3
2. Change to page 2.
3. Set the Mode Code Interface? field on this screen to Y.
5.2 ANALOG VOICE PORTS ADMINISTRATION
o Define the integrated analog voice ports that will connect to the
Intuity using the ADD STATION command. Sequential numbering is
recommended. The FEATURE OPTIONS must be configured as
follows. (Refer also to Table 2.) Repeat for each analog port.
Type: VMI
Name: VOICEMAIL
Tests? N
LWC Reception? N
LWC Activation? Y
Switchhook Flash? Y
Adjunct Supervision? Y (Open Loop Disconnect)
Define the analog voice ports
that will connect to the Intuity
system
All other fields can set to no or default.
Configuring Hunt Group for the
Intuity ports
5.3 HUNT GROUP ADMINISTRATION
After all the analog lines to be connected to the Intuity ports are
configured, they need to be installed into a Hunt Group.
o Define the Hunt Group on the PBX by entering “add hunt-group
<hunt group number> or “add hunt-group next” for the next
available hunt group number. Configuring the hunt group as “ucd” is
recommended. Below is an example of how a hunt group is
configured:
ADD HUNT-GROUP 11
Add hunt-group 11 Page 1 of 6
HUNT GROUP
Group Name: VOICEMAIL
Group Number: 11 Group Extension: 5000 Group Type: ucd
ACD? n
Queue? y Vector? n
Security Code: COR: 1
ISDN Caller Disp: grp-name
3
TN: 1
Queue Length: 15
Calls Warning Threshold: Calls Warning Port:
Time Warning Threshold: Time Warning Port:
Note:
3
Enter grp-name to specify the hunt group name be sent to the
originating user. This field is required when the ISDN-PRI option on the
switch System-Parameters Customer-Options screen is enabled.
