Avaya IP600
Rack Mount Cabinet Installation
EXIT
. Circuit pack installation
! Warning: When handling circuit packs or any components of a DEFINITY ONE system,
always wear an authorized wrist ground strap. Connect the strap to the ground
connector provided on the system cabinet. See Figure 13.
! Note: All of the circuit pack slots in the CMC are “universal slots.” Any slot can contain
any type of port circuit pack.
Circuit pack slot loading.
Install the TN795 Processor circuit pack in slot 2 of the cabinet. See Figure 13
A TN744D Call Classifier/Tone Detector circuit pack is required. Slot 3 is
preferred.
Load all port circuit packs. See the table in the IP600 installation manual for
recommended layout.
