Avaya DEFINITY ONE Installation

9
Avaya IP600
Rack Mount Cabinet Installation
–EXIT
– Install patch panel and shelf
• Using the supplied mounting screws, mount the patch panels on the rack below
the processor cabinet.
• Using the supplied mounting screws, mount the shelf on the rack below the
patch panels.
• Attach B25A cables to the circuit pack amphenol connectors and to the patch
panels.
! Connect 24-port DCP or analog circuit packs to the 24-port patch panels
! Connect 8-port analog trunk, “combo,” or DID trunk circuit packs to either of the first two
banks on the 8-port patch panel.
! Connect 8-port BRI trunk (TN2185B), if present, to the third bank on the 8-port patch
panel.
NOTE: The patch panels don’t have to be mounted in the same rack as the
cabinet; they can be located in phone closets, as appropriate.
