8
Avaya IP600
Rack Mount Cabinet Installation
EXIT
Install the upper terminator of the TDM/LAN bus cable on the right end of the
TDM/LAN bus in cabinet B.
Reinstall the routing slot plates (now rotated).
Reinstall the fan assemblies and the bottom panel.
. Install patch panel and external modem
The cabinet may come with a patch panel kit rather than the traditional
110A cross connect kind of gear. The patch panels are arrays of RJ45
jacks and associated B25A cabling to accommodate 2-wire, 24-port DCP
or analog port boards, and 8-port analog trunk boards. See Figure 12
A shelf is provided to route the B25A cables and to provide a mounting
surface for the external modem (and other optional equipment) See
Figure 12 .
! Note that you may use a locally obtained, type-approved external modem (V.34
protocol). Contact your Avaya representative for more information.
! Warning: If you use a modem other than the U.S. Robotics modem, it must be
configured in NT.
Traditional 110A cross-connect gear may be used.
