Avaya IP600
Rack Mount Cabinet Installation
EXIT
. Cable the system
Install Processor Interface cable and the IP Media Processor adapter and
259A C-LAN adapter. See Figure 8
Cable a two-cabinet system.
Remove the bottom panel and fan assembly (if not already removed) from the
top cabinet (port cabinet).
Remove the fan assembly (if not already removed) from the bottom cabinet
(processor cabinet).
Remove the right TDM/LAN bus terminator from cabinet A and install it at the
left end of cabinet B. See Figure 9
Remove the nuts on the posts of the plate covering the bottom right routing slot
of cabinet B and the plate covering the top right routing slot of cabinet A. See
Figure 10
Pull open the EMI gasket, and pass the TDM/LAN cable through the routing
slots in both cabinets. Push the free end of the EMI gasket back in place. See
Figure 11.
Install lower terminator of the TDM/LAN cable on the right end of the TDM/LAN
bus in cabinet A.
