3
Avaya IP600
Rack Mount Cabinet Installation
EXIT
. Install the system cabinet
Single cabinet systems can be rack-mounted (preferred) or floor-
mounted.
Floor Mount: The bag of fasteners included with the primary cabinet has screw-
in plastic feet.
Double cabinet systems must be rack-mounted.
Make sure that the standard 19” rack equipment provided by the
customer has been properly installed and solidly secured to the floor.
NOTE: If the rack is not solidly secured, do not proceed with the installation.
Rack Mount steps:
Install one mounting screw on each side of the rack in the at the desired height
for the top of the cabinet. Do not tighten the screw -- leave enough space
between the screw head and rail surface to accept the mounting bracket. Note
that the screw holes are not evenly spaced. See Figure 2 for proper
positioning.
Remove the door, CPs, and the 650A power supply from the RMC; then
carefully lift the cabinet to the desired level (not higher than shoulder level
unless two people are lifting) and position the keyholes over the screws. See
Figure 3
