4
Avaya IP600
Rack Mount Cabinet Installation
–EXIT
. Install the system cabinet
• Let the weight rest on the screws while adding the other six screws; tighten all
eight screws.
• If installing a second cabinet, mount it above the first cabinet with minimum
space between the cabinets. Before mounting the second cabinet, install the
rectangular EMI gasket over the right routing slot on top of the first cabinet. Be
sure that open corner of gasket faces the rear of the cabinet. Be sure to mount
the second cabinet on the rack with screws; do not it leave it resting on the
bottom cabinet. If mounted properly, the top cabinet will slightly compress the
gasket.
– Remove the fan assembly and verify the carrier address ID on cabinet(s).
See Figure 4 and Figure 5.
– The 650A power supply is the same unit as provided with the CMC
cabinet. The pre-existing instructions apply here. To summarize:
• Warnings:
! The alternating current(AC) power circuit must be dedicated to the system. The circuit
must not be shared with other equipment and must not be controlled by a wall switch.
The AC receptacle must not be located under the Main Distribution Frame and must be
easily accessible.
