Page #5 background imageLoading...
Page #5 background image
5
Avaya IP600
Rack Mount Cabinet Installation
EXIT
! System grounding must comply with the general rules for grounding provided in Article 250 of
the National Electrical Code (NEC), National Fire Protection Agency (NFPA) 70, or the
applicable electric code in the country of installation.
! AC mains wiring and testing must be performed by a qualified electrician ad must conform to
Article 250 of the NEC, NFPA 70 , or the applicable electric code in the country of installation.
Danger: see Figure 6
! The latch on the 650A power supply only removes direct current (DC) power from the
cabinet. Unseating the power supply removes AC power from the power supply, but not from
the cabinet. To remove AC power from the cabinet, pull the AC power cord from the AC
appliance connector on the rear of the cabinet.
Check AC power and ground
The 650A power supply provides auto-ranging (85 to 264 VAC), 47 - 63 Hz, 330
Watts, 4.5 Amps (100 - 120VAC) or 2.3 Amps (200 to 240 VAC), at 500 VoltAmps
(VA).
The AC power source can be 1 phase of 120VAC with neutral (100 VAC for Japan)
with 15-Amp circuit breaker, or 1 phase of 220 or 240 VAC (200 VAC for Japan) with
10-Amp circuit breaker. The AC cord uses a NEMW5-15P plug or and !EC 320
plug.
Before powering up the system, check the AC power in the equipment room using a
KS-20599 digital voltmeter (DVM) (or equivalent). For details see the Installation
Manual that ships with the system.
Approved Grounds: as in all installations, an approved ground must be assured.
For details see the Installation Manual that ships with the system.
