Install and Cable the Cabinet
1-123Install off-premises station wiring
1
Circuit protectors
Both building entrances require carbon block or equivalent protection and sneak
current protection. Provide this protection with a 4-type protector. The 4-type
protector is equipped with a heat coil or a 3-type protector plus a separate sneak
current protector.
The 4-type protector is the preferred device. For installations not using primary
protection, always use 4-type protectors. When the 3-type protector is already
installed, a separate sneak current protector is required. The multi-pair protector
units and the off-premises cabling must be locally engineered. Connectorized
multi-pair protector units (female 25-pair connector) are recommended.
Table 1-21 shows the recommended protectors.
The maximum range of out-of-building analog telephones (500-, 2500-, or
7100-types) connected to an analog line circuit pack should be such that the
maximum loop resistance does not exceed 1300 Ohms.
The following voice terminals
cannot be installed in an exposed environment:
■ 7300-type voice terminals connected to TN762 Hybrid Line circuit packs
■ Multi-button Electronic Telephone (MET) sets connected to TN735 MET
Line circuit packs
■ Analog telephones connected to TN746 Analog Line circuit packs
See Table 1-3 on page 1-8 for circuit protector ordering information (comcodes).
Table 1-21. Analog line circuit protectors
Primary
1
1. The 3-type protectors should only be used if they are already part of the existing
protection system. A sneak current protector is always required when a 3-type
primary protector is used.
Primary
(with heat coil)
Sneak current
protectors
1
3B1A (carbon) 4B1C (carbon) 220029 Fuse
3B1E-W (wide-gap
gas tube)
4B1E-W (wide-gap gas tube) SCP-1
3C1S (solid state) 4C1S (solid state)
