AVer VB342 Pro User Manual

FEDERAL COMMUNICATIONS COMMISSION
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radiofrequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Warning:
This is a class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe
A est conforme à la norme NMB-003 du Canada.
この装置は、クラス A 機器です。この装置を住宅環境で使用すると電波妨害を引き起こすことがあります。
この場合には使用者が適切な対策を講ずるよう要求されることがあります。 VCCI-A
사 용 자 안 내 문
이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서
가정용 환경에서 사용하는 경우 전자파간섭의 우려가 있습니다.
※ 사용자 안내문은 "업무용 방송통신기자재"에만 적용됩니다.
기종별
사용자안내문
A 급 기기
(업무용 방송통신기자재)
이 기기는 업무용(A 급) 전자파적합기기로서 판
매자 또는 사용자는 이 점을 주의하시기 바라
며, 가정외의 지역에서 사용하는 것을 목적으로
합니다.

AVer VB342 Pro Specifications

General

Pan range	0 - 180 °
Product type	Group video conferencing system
Product color	Black
Tracking modes	Presenter mode
Wall mountable	Yes
Tilt angle range	0 - 105 °
Number of persons	- person(s)
Cable lock slot type	Kensington
Sound pressure level (max)	96 dB
Megapixel	- MP
Sensor type	-
Aspect ratio	4:3, 16:9
Optical zoom	3 x
PTZ protocols	Pelco-P/D, UVC, VISCA
White balance	Auto, Manual
Image sensor size	- \
Diagonal field of view	92 °
Vertical field of view	53 °
Horizontal field of view	84 °
Number of camera presets	10
Remote control interface	IR Wireless
Closest focusing distance	0.8 m
Optical zoom (super-wide mode)	15 x
Processor model	i5-4460
Processor family	Intel® Core™ i5
Applications supported	Zoom, Microsoft® Teams, Skype, Skype for Business, Google Meet, RingCentral, BlueJeans , Intel® Unite™, Fuze, Adobe® Connect™, CyberLink U Meeting®, Cisco WebEx® GoToMeeting™, LiveOn, Microsoft® Lync™, TrueConf, V-Cube, Vidyo, vMix, WebRTC, Wirecast, XSplit
Windows operating systems supported	Windows 10, Windows 11, Windows 7
Maximum frame rate	60 fps
Video formats supported	H.264, H.265, M-JPEG, YUV, YUY2
Maximum video resolution	3840 x 2160 pixels
Resolution at capture speed	3840x2160@30fps
Supported graphics resolutions	480 x 360, 640 x 360, 640 x 480 (VGA), 800 x 448, 800 x 600 (SVGA), 848 x 480, 960 x 540, 1280 x 720 (HD 720), 1280 x 960, 1600 x 900, 1920 x 1080 (HD 1080), 3840 x 2160
Speaker power	6 W
RMS rated power	12 W
Number of speakers	2
Microphone pick-up range	8 m
AC input voltage	100 - 240 V
DC output current	5 A
DC output voltage	12 V
Power source type	AC
AC input frequency	50 - 60 Hz
Minimum RAM	4000 MB
Minimum processor	Intel® Core i5-4460
Minimum processor speed	3.2 GHz
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, USB Type-A to USB Type-B, USB Type-A to USB Type-C
Power cable length	3 m
RS-232 ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mounting type	Stand/Wall mounting
LED indicators	Status
Warranty period	3 year(s)

Weight and Dimensions

Depth	116 mm
Width	738 mm
Height	127 mm
Camera weight	3100 g
Package depth	197 mm
Package width	872 mm
Package height	260 mm
Package weight	6300 g
Remote control weight	50 g
Camera dimensions (WxDxH)	738 x 127 x 116 mm
Remote control dimensions (W x H x D)	149.72 x 42.3 x 19.3 mm
