Avery Weigh-Tronix 7821 - Configuration Options; Calibration Procedures

7821 User Instructions 15
5.2 Gravity Adjustment
5.2.1 Alternative Calibration Span Points
5.2.2 Baud Rate and Parity Options
*Factory Default Setting
Table 5.1 Alternative Calibration Span Points
Capacity lbs
Alternative
Calibration
Weights (lbs)
Capacity (kg)
Alternative
Calibration
Weights (kg)
150 x 0.05 lb 10, 50, 150
60 x 0.02 kg
70 x 0.02 kg
75 x 0.02 kg
10, 30, 60
10, 30, 70
10, 30, 75
150 x 0.02 lb 10, 50, 150 75 x 0.01 kg 10, 30, 75
200 x 0.05 lb 10, 100, 200 100 x 0.02 kg 10, 50, 100
Table 5.2 Baud Rate and Parity
Options
Display Baud Parity
12 E 1200 Even
48 E 4800 Even
*96 E 9600 Even
192 E 19,200 Even
12 o 1200 Odd
48 o 4800 Odd
96 o 9600 Odd
192 o 19,200 Odd
12 n 1200 None
48 n 4800 None
96 n 9600 None
192 n 19,200 None
