Installation and Setup 18
Connecting a Footswitch
The S1 has a 1/4-inch footswitch input on the back panel, which can be configured in EuControl Settings to control punch in and
out of recording in your DAW, or for engaging talkback.
For more information on configuring the footswitch, see the Using EuControl Surfaces.pdf.
Enabling EUCON in Pro Tools
When you first connect an Avid media controller you must enable EUCON in Pro Tools. EUCON subsequently remains enabled
in Pro Tools unless you disable it. To enable EUCON in other DAWs, see the documentation provided by the manufacturer, as well
as the EUCON Application Setup Guide.pdf.
To enable EuControl in Pro Tools:
1 Launch Pro Tools. If the Quick Start dialog appears, close it.
2 Choose Setup > Peripherals, and click the Ethernet Controllers tab.
3 Select Enable EUCON.
4 Click OK. You do not need to configure any other Ethernet Controllers settings. These settings do not apply to EUCON.
Pro Tools scans your system until it identifies attached EUCON-compatible hardware. When Pro Tools finishes scanning your
system, your controllers are ready to use with Pro Tools.
5 Proceed to Confirming EUCON.
Footswitch input on the back of S1
Enable EUCON check box
While Pro Tools is connected to a EUCON surface do not uncheck to disable and re-check to enable without a complete restart
of all components (surfaces and Pro Tools computer) after disabling and before re-enabling.
