Appendix A: Specifications 32
Appendix A: Specifications
All specifications subject to change.
Module:
Avid S1
Mechanical
Avid S1 Mechanical Specifications
Environmental
Avid S1 Environmental Specifications
Parameter Specification
Height (front) 1.3 in (33 mm)
Height (rear) 4.1 inches (103 mm)
Width 12.4 in (316 mm)
Depth 14.9 in (377 mm)
Weight 4.17 lbs
1.89 kg
Power Requirements 2.8 A
Ethernet Port 1000-BaseT (Gigabit) Ethernet RJ-45
Parameter Specification Limit Units Condition/Comment
Storage Temperature –18 to +60 deg C deg C 0 to +140 deg F
Operating Temperature +4 to +40 deg C deg C +40 to +104 deg F
Storage humidity range 5 to 95 % Non-condensing
Operating Humidity Range 20 to 80 % Non-condensing
Continuous Vibration (Storage
only: non-powered transportation)
1 g RMS Random spectrum
