Avidsen YLVA 3+ - Product Description; Contents of the Kit; Monitor Overview

6
EN
COLOUR VIDEO INTERCOM 7"
B - PRODUCT DESCRIPTION
1 - CONTENTS OF THE KIT
2 - MONITOR
1 7" LCD screen
2 Microphone
3 Photo viewing button or menu
access (hold for 5 secs)
4 Door opening/camera button (if
connected) or top arrow
5 Electric strike plate button or bottom
arrow
6 Handset button to answer calls,
call another monitor (ref. 112279) or left arrow
7 Surveillance mode to view the intercom panel
or right arrow
1
x 1
5
x 5
6
x 1
7
x 1
2
x 1
8
x 4
3
x 1
4
x 5
1 Monitor
2 Intercom panel
3 Monitor wall bracket
4 Dowels (2 for the monitor, 3 for the intercom
panel)
5 Screws (2 for the monitor, 3 for the intercom
panel)
6 Screws for the intercom panel
7 Mains adapter
8 RFID badges (red x1, grey x1, blue X2)
9
8
3 4 5 6 7
1
2
10
